5-4

5. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark

..2 M0215 BN07-00622A LCD-PANEL;M216H1-L01,CM21H11,6bit Hi-FRC 1 SA

0.1 BN91-03699B ASSY SHIELD;P2270H,ECOFIT 1 SNA

..2 CIS1 BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915, 0.12 SNA

0.1 M0017 BN91-04511A ASSY CHASSIS;LS22EFVKUU/EN 1 SNA

..2 M0081 6003-001023

SCREW-TAPTYPE;PWH,+,-

,B,M3,L10,ZPC(WHT),

2 SNA

..2 M0215 BN44-00308B INVERTER;Ecot21.5,23"W,GH329B,60khz,14 1 SA

...3 M0014 BN94-03208U ASSY PCB MISC-MAIN;LS23EFP*,BN44-00308B, 1 SNA

....4 BN81-04470A A/S-CAPACITOR;NXH Series 220uF/35V 8*11 2 SNA

....4 BN81-04485A A/S-TRANSFORMER;GT-828,燛FD1323 4 SNA

....4 T0174 BN97-03934U ASSY SMD;IPB-M308B/ZB,BN41-0* 1 SNA

.....5 BN81-02499A A/S-FET-SILICON;0505-001902 1 SNA

.....5 BN81-04471A

A/S-CAPACITOR;GRM188R71H103K,10nF,10%

,X7

2 SNA

.....5 BN81-04472A

A/S-CAPACITOR;GRM188R71H122K,1.2nF,10

%,X

1 SNA

.....5 BN81-04473A

A/S-CAPACITOR;GRM1885C1H561J,560pF,5%

,CO

6 SNA

.....5 BN81-04474A

A/S-CAPACITOR;GRM188R71A684K,680nF,10

%,X

1 SNA

.....5 BN81-04475A

A/S-CAPACITOR;GRM188R71H104K,100nF,10

%,X

2 SNA

.....5 BN81-04476A

A/S-

CAPACITOR;GRM188F51E105Z,1uF,-20%~80

3 SNA

.....5 BN81-04477A

A/S-CAPACITOR;GRM188R71E473K,47nF,10%

,X7

2 SNA

.....5 BN81-04478A

A/S-CAPACITOR;GRM21BR61E475K,4.7uF,10

%,X

4 SNA

.....5 BN81-04479A A/S-RESISTOR;MCR03EZPJ104,100K#,1/10W,16 1 SNA

.....5 BN81-04480A A/S-IC;BD9893F,CCFL Controller 1 SNA

.....5 BN81-04481A A/S-FET;APM4548AK,30V7.4A,-30/-6A, SO-8 2 SNA

.....5 BN81-04482A A/S-ZENER-DIODE;UDZS12B,Vz11.74~12.24V,I 1 SNA

.....5 BN81-04483A A/S-ZENER-DIODE;UDZS16B,Vz15.85~16.51V,I 2 SNA

.....5 BN81-04484A A/S-ZENER-DIODE;UDZS9.1B,Vz8.85V~Vz9.23V 2 SNA

.....5 BN81-04486A A/S-FUSE;CCF1N5TTE,100Vdc, 5A 1 SNA

.....5 BN81-04487A

A/S-CONNECTOR;12507WR-12L,1.25mm Pitch,

燛 1.000

SNA

.....5 BN81-04488A A/S-CONNECTOR;35001WR-04L 2 SNA

.....5 M0561 BN81-04489A A/S-PCB;GH329B,REV1.0,110*75,1.0T 1 SNA

.....5 BN81-00608A A/S-DIODE-ARRAY;0407-000122,-,-,-,-,-,- 10 SNA

.....5 BN81-00610A A/S-TR-SMALL SIGNAL;0501-000457,-,-,-,-, 1 SNA

.....5 BN81-00639A A/S-R-CHIP;2007-000308,-,-,-,-,-,- 1 SNA

.....5 BN81-01132A A/S-R-CHIP;2007-000090 2 SNA

.....5 BN81-01353A A/S-R-CHIP;2007-000060,-,-,-,-,-,- 3 SNA

.....5 BN81-01357A A/S-R-CHIP;2007-000130,-,-,-,-,-,- 2 SNA

.....5 BN81-01358A A/S-R-CHIP;2007-000247,-,-,-,-,-,- 3 SNA

.....5 BN81-01366A A/S-R-CHIP;2007-000910,-,-,-,-,-,- 1 SNA

.....5 BN81-01371A A/S-R-CHIP;2007-001206,-,-,-,-,-,- 1 SNA

.....5 BN81-01982A A/S-R-CHIP;2007-000067 1 SNA

.....5 BN81-01987A A/S-R-CHIP;2007-001096 1 SNA

.....5 BN81-01988A A/S-R-CHIP;2007-001116 1 SNA

.....5 BN81-02528A A/S-R-CHIP;2007-000219 1 SNA

.....5 BN81-02829A A/S-R-CHIP;2007-000026 4 SNA

.....5 BN81-02908A A/S-CHIP-RESISTOR;2007-000052 1 SNA
