5-3
5. Exploded View & Part List
5-2. LS22EFVKU/XF Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.1 BN90-02324A ASSY COVER FRONT;P2270H,ECOFIT 1 SNA
..2 T0003 BN96-09622J
ASSY COVER
P-FRONT;LS22EF,PMMA+ABS,ROSE
1 SC
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 SA
...3 AB258 BN61-05849A BRACKET-PANEL;P2370H,SECC,T1.0 1 SNA
...3 BN63-01474G FELT-STAND;ECOFIT23"(P2370),T0.35,20,127 1 SNA
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.04,680mm,20 0.6 SNA
...3 T0527 BN68-00798D LABEL-ENERGY,STAR;L/M,W/W,PET,T0.05,9.3, 1 SNA
...3 M0020 BN96-10522B ASSY BOARD P;Ecot,Function Assy,With H 1 SA
....4 M0020 BN96-10522A ASSY BOARD P;Ecot,Function Assy,Withou 1 SA
.....5 T0172 BN94-02622R ASSY PCB MISC-ECOFIT,F/PCB,BN96-10522A;E 1 SNA
......6 T0260 BN64-01023A
KNOB-CONTROL MIRROR;ECOFIT
23",ABS,HB,WH
1 SNA
......6 T0186 BN64-01024A INLAY-PLATE;P2370,ECOFIT 23",PET SHEET,T 1 SNA
......6 BN74-00025A
TAPE-FUNCTION TAPE;DOUBLE FACE
TAPE,Poly
1 SNA
......6 BN74-00026A
TAPE-FUNCTION TAPE;DOUBLE FACE
TAPE,Poly
1 SNA
......6 T0174 BN97-03017N ASSY SMD;ECOFIT,F/PCB-SMD 1 SNA
.......7 L0405 0601-002331 LED;SMD,(SIDE VIEW ),WHT,2.04mm 6 SNA
.......7 FAR22 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SNA
.......7 AD480 2203-006618 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,TP,160 2 SNA
.......7 HB01A 3711-005743
HEADER-BOARD TO
CABLE;BOX,5P,1R,1.25mm,A
1 SA
.......7 BN41-01189A PCB-FUNCTION;Ecot Function PCB,FR-4,2, 1 SNA
.......7 BN81-03258A A/S-MCS-5000 ECOFIT;ECOFIT PROJECT,1209- 1 SNA
....4 M2893 BN39-01164A
LEAD CONNECTOR;ECOFIT,UL1571#30,5P,10
0mm
1 SA
...3 M0112 BN63-05426M
COVER-FRONT;LS22EF(21.6),PMMA
ABS,HB,TTP
1 SNA
0.1 M0002 BN90-02325A ASSY COVER REAR;P2270H,ECOFIT 1 SNA
..2 M0013 BN96-12301A ASSY COVER P-REAR;Ecot21.6,BLACK,HB,BK 1 SA
...3 M0081 6003-001001
SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SW
RC
1 SNA
...3 M0081 6003-001239
SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),S
WR
2 SNA
...3 CIS4 BN61-05084A HOLDER-STAND;ECOFIT 23",ACETAL,WHITE 1 SNA
...3 T0060 BN61-05090A SPRING ETC;ECOFIT 23",SK5,T0.5 1 SNA
...3 T0060 BN61-05091A SPRING ETC-STAND;ECOFIT 23",SK5,T0.3 1 SNA
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.04,680mm,20 0.7 SNA
...3 M0111 BN63-05442A
COVER-STAND;P2370, ECOFIT
23",PMMA+ABS,H
1 SNA
...3 M0006 BN63-06192A
COVER-REAR;ECOFIT
21.6",ABS+PMMA,HB,BK23
1 SNA
...3 BN63-06193A SHIELD-LAMP;ECOFIT 21.6",SPTE,T0.3 1 SNA
...3 BN73-00162A
RUBBER-PANEL;943BW/
NW,RUBBER,BLACK,(Wide
3 SNA
...3 M0131 BN63-00209A
GASKET;RS24NS,CONDUCTIVE
FAB,4mm,10mm,30
1 SNA
0.1 BN91-03053C ASSY LCD-CTZ;LS22MY* 1 SNA
