Samsung PS50A410 - Wall- Mount Adjustment (Sold Separately)

English - 33
Entering the menu
1 Pressthe▲,▼,◄or►buttononyourremotecontrol.
➢
The Wall Mount Adjustment screen is displayed.
➢
If the Wall Mount Adjustment screen is not displayed
when clicking on a direction button while watching your
TV, use the menu to display that screen.
• Press the
MENU button to display the menu. Press the
▲or▼buttontoselect
Setup, then press the ENTER
button.
 •Pressthe▲or▼buttontoselect
Wall-Mount
Adjustment, then press the ENTER button.
Remembering the Position
2 Adjusttothedesiredpositionusingthe▲,▼,◄,►buttons.
➢
If you press an arrow button when no OSD is displayed
on the TV screen, the Adjustment screen appears.
➢
Press the INFObuttontoreset.Pressthe◄or►button
to select Yes, then press the ENTER button. The position
is initialized to the default setting.
3 Press the blue button.
Pressthe▲and▼buttonstoselectasavemodefrom
either Position1, Position2 or Position3 in order to save the
current position.
➢
To not save the current position, press the RETURN
button.
➢
When selecting a save mode, you cannot use the Color
buttons.
4
Press the ENTER button to save.
➢
When Position1 is selected, the message Current
position saved as Position1 is displayed.
5
Press the ENTER button.
➢
The saved Position appears on the left side of the OSD.
Wall- mount adjustment (Sold separately)
Once the auto wall mount is installed, the position of your TV can be easily adjusted.
Rear Panel Auto Wall-Mount
Serial Cable(1P to 1P)(Not supplied)
Move Enter Return
Plug & Play

Language : English 
Time 
Light Effect : In Watching TV 
Wall-Mount Adjustment 
Melody : Off 
Entertainment : Off 
Energy Saving : Off 
PIP

Setup
T V
Save
Return
Move
Enter
Select a mode to Save.
Position 1
Position 2
Position 3
Wall-Mount Adjustment
Adjust
Save Center
►
►
►
►
►
►
►
►
321Position
