7-5

R530/R730

7. System Wire Diagram

- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -

- This Document can not be used without Samsung's authorization -

7-5. System wire diagram (17.3)

LCD Cable

USB Sub Board

Cable

ODD FFC

Camera Cable

WLAN Antenna

Cable 2ea
