20
DISASSEMBLY AND REASSEMBLY
3-3 ) Freezer Door(RB215,RB195)
Part Name How To Do Descriptive Picture
Freezer Door
2. Remove the Middle Hinge
connected to the Freezer.
3. Disassemble the Freezer door
by lifting it upward. Be careful
not to drop and scratch the
Freezer door
4. Disassemble the Cap on the
Low Hinge.
3-3 ) Freezer Door(RB217AC,RB197AC)
Freezer
Door
Part Name How To Do Descriptive Picture
1. After opening the Freezer door,
separate drawer box
NW-미주향-AC 2010.6.8 3:46 PM 페 이 지 2 0 i n
To Next Page
