38
1) For example, if you want to change freezer compartment standard temperature to -4℉(-2℃) by
operating option, do as below. This function is for changing the standard temperature. In -2℉(-19℃) of
current temperature of freezer compartment, if you make the temperature lower to -℉(-2℃) by the
option, the standard temperature would be controlled -6℉(-21℃) Therefore, if you change the setting of
temperature option to -2℉(-19℃) on the panel, the appliance will be operated with -6℉(-21℃). It means
that standard temperature is controlled -4℉(-2℃) less than setting temperature in the display.
TROUBLESHOOTING
Key control in option mode
Power Freeze Key
Freezer Key
Power Cool key
Fridge key
Code Down key
Code Up key
Reference Value down key
Reference Value Up key
●
If the display changes to option setting mode, all displays will be off except freezer and fresh food
compartments temperature display as below. (Fresh food and freezer compartments is explained only
because all options are operated with the same method according to the option table.)
Basically, option function has cleared data at shipping process. Therefore, all setting value are
"0". But, check the quality information manual or specifications, because setting value could be
changed particularly for the purpose of improving quality at mass producing process.
NOTE
① If Freezer Key + Power Cool Key are pressed simultaneously for 12
seconds, option setting mode will be started.
To Next Page
