Samsung RF197ABWP - Freezer Door Assembly Disassembly

19
DISASSEMBLY AND REASSEMBLY
Refrigerator
Door
Part Name How To Do Descriptive Picture
6. Lift the door straight up to
remove.
Be careful not to drop and
scratch the doors while
removing the doors.
7. Separate the cap on the middle
hinge.
3-3 ) Freezer Door(RF195)
Freezer Door
Part Name How To Do Descriptive Picture
1. Remove the screw attached to
the left and right middle hinges
with a philops screwdriver(+).
Remove the 2 hex head bolts
attached to the left and right
middle hinges with an allen
wrench(3/16”).
