22
DISASSEMBLY AND REASSEMBLY
3-5) Refrigerator Light
Refrigerator Light
Part Name How To Do Descriptive Picture
1. Remove the lamp cover by
pulling it down as pushing the
rear of lamp cover.
2. Remove the lamp by turning
counterclockwise.
3-6) Glass shelves
Glass shelves
Part Name How To Do Descriptive Picture
1. When pulling out the shelf, if it is
not slid out well, lift it up slightly
and pull out again.
To Next Page
