setting up
08_
Fix the handles to the doors by sliding them left
side firmly.
4
3
2012.3.31 9:49:32 AM
2
1
Fix the handles to the doors by
sliding them down firmly.
3
5
4
Tighten with wrench fi
Drawer door handle assembly
Check the direction of Handle
assembly.
1
2
Fix the handles to the doors by
sliding them left side firmly.
5
Tilt up the Handle bar and tighten with wrench
firmly.
Disassemble the refrigerator doors
Be careful not to drop and scratch the
doors while removing them.
With the door opened
Remove 3 screws holding down the TOP 1.
TABLE ( 1 ) and turn it with wires connected.
Disconnect two connector (
2
) on the left side
door. To remove the water coupler from the
WARNING
2
1
hinge, twist and pull it from the hinge.
