Samsung RF26V - Adjusting the Freezer Drawer Level

Setting Up 
01 

1. Locate the height-adjuster (

) in the freezer drawer.
Unscrew the four Phillips screws (
2
) slightly to loosen the door.
2. Loosen the controller screw(
3
) with a Phillips
screwdriver.
3. Find the best level to align the door slope.
Freezer Drawer
Adjustment part

2
3
Example) The slope is about 2mm (0.08inch) as shown below.
- Rotate the Height Adjuster to +2.0 to reduce the door
slope.
Slope
Reference
plane
