Samsung RF28T5021 - Page 25

English 25
Installation
Right door
1. Gently draw up the clamp. To prevent
nger injuries, do not apply a sudden
force to the clamp.
2. Pull the clamp to remove it.
NOTE
Be careful not to drop the clamp on the
oor.
3. Open the door 90 degrees. While
holding the door, pull up and remove
the top hinge. Be careful not to damage
the connector wires when you remove
the hinge.
NOTE
Be careful not to drop the hinge on the
oor.
