Samsung Electronics 13
1. Take out the case from the freezer.
2. Remove 2 screws from the holder of the cooling
cycle unit.
3. Pull out the holder of the cooling cycle unit and
disconnect wire terminals.
3-3. Disassembly of the cooling cycle unit in the freezer
2 screws
4. Pull forward the insulating material of the cooling
cycle unit and remove the wire terminal and insulating
material.
5. Remove 2 screws securing refrigerator duct and
pull it out by following the arrow.
To Next Page
