Samsung RL36EB - 3-5. Electric box assembly

16 Samsung Electronics
3-5. Electric box assembly
1. Disconnect the power cord.
TEST S/W
Condenser
D/C Trans
3. Assembly specification of electric box
2. Remove the cover of
electrical box with insert
driver.( )
Warning
Make sure the power plug is taken out when replacing the components for the main
PCB.
