setting up _
2. Removing the freezer door
A few things to mention first.
• Make sure that you lift the door straight up so the hinges are not bent or broken.
• Place doors on a protected surface to prevent scratching or damage.
1. With the Freezer door closed, remove the upper hinge cover
1
using a screwdriver, and
then disconnect the wires by gently pulling them apart
2
.
2. Remove hinge screws
3
and the ground screw
4
by turning counter-clockwise, and take
off the upper hinge
5
. Be careful that the door does not fall on you as you are removing it
3. Next, remove the door from the lower hinge
6
by carefully lifting the door straight up
7
.
2
3
4
5
7
6
setting up your side-by-side
refrigerator
10
SE
G
N
I
T
T
UP
1
19
