Samsung RSA1R Series - Making Minor Adjustments to the Doors

setting up _
r n. If you need help,
In the case of the process to correct the imbalance is the same. Open the doors and adjust
them, one at a time, as follows:
1. Unscrew the nut
1
from the lower hinge until it reaches the upper end of the bolt
2
.
When you release the nut
1
, make sure that you use the Allen wrench provided
3
to
loosen the bolt
2
in a counter-clockwise direction. You should then be able to unscrew the
nut
1
with your fingers.
2. Adjust the height difference between the doors by turning the bolt
2
clockwise or
counter clockwise
.
W
hen you turn clockwise , the door will move up.
Adjustment part
3
2
1
Wrench
Bolt
Nut
3
2
W
rench
10 SE GNITT UP
MAKING MINOR ADJUSTMENTS TO
THE DOORS
Remembe efrigerator is necessary for getting the doors perfectly eve
review the previous section on leveling the refrigerator.
, a leveling r
When the door of the freezer is higher
than the fridge
Bolt
3. After adjusting the doors, turn the nut
1
clockwise until it reaches the lower end of
the bolt, then tighten the bolt again w
ith the wrench
3
to fix the nut in place
1
.
If you do not secure the nut firmly, the bolt may release.
3
2
1
Wrench
B
olt
Nut
setting up your side-by-side
refrigerator
25
