Maintenance
English24
Maintenance
A
5. Use a screwdriver to remove the screws
and then detach the middle hinge (A).
A
6. Gently lift the fridge door (A) to remove
it from the bottom hinge.
A
7. Use a screwdriver to remove the screws
fastening the bottom hinge (A).
A
B
8. Use a screwdriver to remove the hinge
bolt (A). Then, use a spanner to remove
the hinge shaft (B).
