English 27
Maintenance
A
17. Remove the top hinge (A) with its cover.
B
A
18. Separate the top hinge (A) and the hinge
cover (B).
A
19. Take out the wires from the hinge cover
(A).
NOTE
Keep the detached hinge cover in a safe
place for later use.
A
20. Use a at-head screwdriver to remove
the hinge grommet (A).
