Maintenance
English26
Maintenance
A
12. Use a at-head screwdriver to remove
the bottom-hinge screw cap (A), and
then reinsert it on the opposite side.
A
13. Remove the leveling leg (A) attached to
the left side of the main unit.
A
14. Attach the leveling leg (A) to the
opposite side.
A
B
15. Remove the auto closer (A) and the
stopper (B) from the bottom of the
fridge/freezer doors. Then, reinsert
them on the opposite side of the fridge/
freezer doors as shown in the gure.
A
16. Pull up to remove the bar cover (A) on
the top of the freezer door.
