DISASSEMBLY & REASSEMBLY

PART NAME DESCRIPTION FIGURE

Main PBA and

Inverter PBA

.revoc ABP eht fo swercs 2 eht evomeR .1

detcennoc srotcennoc gnisuoh lla egagnesiD .2

with Inverter PBA and Main PBA.

pulling the hook out. (Refer to the picture)

3.Remove the Inverter PBA and Main PBA by

Disconnect the Sensor and the Housing.

4. To re-assembly the Main PBA and Inverter PBA

follow the reverse steps 3 to 1.

3-6. Disassembling the Main PBA and Inverter PBA
