English 19
Installation
1. Press to unlock the arrow area of the
dongle cover.
2. Open up the dongle cover.
3. Insert the Smart Home Dongle into the
dongle port in the correct direction.
4. Insert the upper area of the dongle
cover rst, and then close to lock as
shown.
NOTE
The marked area is the cover of the
optional dongle, not a crack or defect.
