JC5 2303-000312 C-FILM,PPF;100nF,5%,63V,TP,7.5x12.5x3.5,5
AC15 2401-000129 C-AL;1000uF,20%,16V,GP,-,10x16mm,5
AC16 2401-000129 C-AL;1000uF,20%,16V,GP,-,10x16mm,5
AC40 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC42 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC44 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC60 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC70 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
JC53 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AC47 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC11 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
AC22 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
AC8 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
FC11 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
AC49 2401-000847 C-AL;220UF,20%,35V,GP,TP,10X12MM,5M
AC27 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
AC41 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
AC43 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
AC48 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
AC66 2401-001889 C-AL;100NF,20%,50V,GP,BK,5X11MM,2MM
JC16 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC10 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC26 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC28 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC30 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC43 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC65 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC16 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC18 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
AC45 2401-001969 C-AL;470uF,20%,25V,GP,TP,10x12.5,5
AC48 2401-001969 C-AL;470uF,20%,25V,GP,TP,10x12.5,5
FC12 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC13 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC1 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC2 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC24 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC25 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC7 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC8 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC9 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BEAD1 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
BEAD2 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
AH92-00226A ASSY-PCB-TUNER;S-2000,LW SECTION S.N.A
AH94-00174A ASSY-MANU-LW BAND PCB S.N.A
VVC1 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S
TFL4 14529-304-610 FILTER CERAMIC;AHCM2-450BL
TX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM
TFL2 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
TFL1 2903-000119 FILTER-CERAMIC;SFE10.7MJA-10-A
TFL2 2903-000119 FILTER-CERAMIC;SFE10.7MJA-10-A
TCON1 3710-000209 CONNECTOR-SOCKET;5P,1R,2mm,STRAIGHT,SN
TCON2 3710-000248 CONNECTOR-SOCKET;9P,1R,2mm,STRAIGHT,SN
TCON3 3711-000827 CONNECTOR-HEADER:BOX,2P,1R,2mm,STRAIGHT,;BOX,2P,1R,2mm,STRAIGHT,SN
TJ1 3722-000372 JACK-RCA;2P/1C,3.5MM,SN,BLK,#16~22
HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL
TIC1 AH14-10008B IC;LA1837,DIP,RF+MPX
TLPF1 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TLPF2 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TL2 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BULK,
TL3 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
ANT AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC
LW AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC
ANT AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC
MW AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC
LW AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT
OSC AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT
MW AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT
OSC AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT
AH39-00117A CABLE-COAXIAL ASSY;-,RCA,170MM,1365#30
FM AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm
PACK AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm
TP3 AH61-40022A STUD-TAP;SPC1,T0.5,BT2,-,-,
AH94-00175A ASSY-MANU-LW BAND PCB(W/ RDS) S.N.A(OPTION)
RX1 2801-003601 CRYSTAL-UNIT;4.332MHz,30ppm,28-AAM,30pF,
AH94-00181A ASSY-TAPG-LW BAND PCB(W/RDS) S.N.A(OPTION)
RZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
RR1 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR5 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR2 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
RC9 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
RC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
RC7 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
RC8 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
RC4 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012
RC5 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012
RC1 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RIC1 AH14-10008E IC;BU1923F,SOP,+5V
AH94-00182A ASSY-TAPG-LW BAND PCB(W/O RDS) S.N.A(OPTION)
TD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TZD1 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64V,500mW
TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ7 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TR30 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4MM
TR44 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR58 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR39 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR57 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR1 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR55 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR18 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR13 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR40 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR41 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR16 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
TR32 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR34 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR61 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR62 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR42 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR63 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR64 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR6 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
TJW41 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TJW42 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR24 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR43 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR53 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR56 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
RT48 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR50 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR52 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR37 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR29 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR23 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
TR4 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR17 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR25 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
TR27 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
TR38 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TR44 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TSR1 2103-000290 VR-SEMI;20Kohm,30%,1/10W,TOP
TC39 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
TC40 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
TC42 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
TC41 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
TC20 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC28 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC29 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC3 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC44 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC7 2203-000429 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,2012
TC1 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC5 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC65 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC33 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,-
TC10 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC13 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC14 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
4-2 Samsung Electronics
