TC15 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC35 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC45 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC6 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC61 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC62 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC32 2203-001132 C-CERAMIC,CHIP;0.68nF,5%,50V,NP0,TP,2012
TC2 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012
TC50 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012
TC63 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
TC64 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
TC51 2203-001619 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,2012
TC21 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
TC46 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
TC12 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC26 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC27 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC30 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC34 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
TC36 2401-001019 C-AL;3.3UF,20%,50V,GP,-,5X7,1.5MM
TC38 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM
TC47 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
TC11 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC17 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC19 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC16 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
TC23 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
TC25 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
TC18 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC43 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC4 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC9 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
AH92-00232B ASSY MAIN PCB;CE OPTION NO A/S S.N.A
2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
AC1 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
AC2 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
AC3 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
AC5 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,8x3,5
AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
AL1 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL2 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL3 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4 AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AH92-00241A ASSY-PCB-POWER;S2000,230V 50/60HZ
AH92-00229A ASSY-PCB-POWER;S-2000,POWER COMMON
PF3 3601-000220 FUSE-FERRULE;250V,200MA,TL,GLASS,5X20MM
PF4 3601-000282 FUSE-FERRULE;250V,4A,TL,GLASS,5.2x20mm
- 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
PF3 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
PF4 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
PWF2 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRAIGHT,SN
PCON1 3711-003112 CONNECTOR-HEADER;BOX,8P,1R,2.5MM,STRAIGHT,SN
AH92-00230A ASSY-PCB-POWER;S-2000,POWER,220V-240V,50/60HZ
AH92-00244B ASSY-PCB-FRONT;S-2100/2200/2300 S.N.A
AH92-00236A ASSY-PCB-H/PHONE;S2000,W/CE AREA S.N.A
HR1 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
HR2 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
HC3 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
HC4 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
HL1 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
HL2 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
AJ2 3722-000495 JACK-PHONE;11P,3.5MM,-,AG
ACON1 AH39-00104A LEAD CONNECTOR-ASSY;-,35023,51004,5P,200MM,1007#
AH94-00173A ASSY-MANU-FRONT PCB;S2000 S.N.A
UC29 2409-000123 C-EDL;47000UF,4UA,5.5V,-,BK,-,5MM
UX1 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
UX2 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM
UCW1 3708-000451 CONNECTOR-FPC/FC/PIC;16P,1.25MM,STRAIGHT,
FCW1 3708-000452 CONNECTOR-FPC/FC/PIC;19P,1.25mm,STRAIGHT,
VFD AH07-00012A V.F.DISPLAY;-,HNA-08SS23,S2000,-
UIC1 AH09-00018C IC-MICOM;LC866XXX,-,-,-,-,-,S2000
FWC2 AH39-00101A LEAD CONNECTOR-ASSY;-,5295,51004,5P,150MM,1007#
AH94-00184B ASSY-TAPG-FRONT-PCB; S.N.A
UD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD14 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
UD15 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
UD3 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
UD4 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
UQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
UQ2 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
UQ3 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
UQ4 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92,
ULED1 0601-001232 LED;TR,LED,1PCS,130-260%
ULED2 0601-001232 LED;TR,LED,1PCS,130-260%
ULED3 0601-001232 LED;TR,LED,1PCS,130-260%
UR64 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
UR65 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
UR66 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
UR40 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR13 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR14 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR16 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR18 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR21 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR23 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR5 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR6 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR33 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
UR39 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
UR45 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
UR34 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
UR40 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
UR46 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
FR100 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
UR73 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
UR74 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
UR75 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
UR38 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
UR44 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
UR50 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
UR1 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR12 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR13 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR14 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR15 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR17 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR19 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR20 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR22 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR24 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR28 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR29 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR3 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR30 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR31 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR32 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR59 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR60 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR72 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
UR62 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
UR63 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
UR69 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
UR70 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
UR35 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
UR41 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
UR47 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
UR26 2007-000565 R-CHIP;220KOHM,5%,1/10W,DA,TP,2012
UR36 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
UR42 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
UR48 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
UR25 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR52 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR53 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR54 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR55 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR56 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR57 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR58 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR76 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR77 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
UR61 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
UR27 2007-000947 R-CHIP;47OHM,5%,1/10W,DA,TP,2012
UR37 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
UR43 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
UR49 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
UR71 2007-001654 R-CHIP;10MOHM,1%,1/10W,DA,TP,2012
UR71A 2007-001654 R-CHIP;10MOHM,1%,1/10W,DA,TP,2012
UC1 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC10 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC22 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC24 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC9 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC90 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC91 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC92 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC93 2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,3.5x19,-
UC38 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,-
UC39 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,-
UC11 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
UC12 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
UC13 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
UC2 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
UC21 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 5-3
