Specifications
Chapter 07
General
Model Name S22C31* S24C31* S27C31*
Size
22 Class (21.5 Inches / 54.6 cm) 24 Class (23.8 Inches / 60.4 cm) 27 Class (27 Inches / 68.6 cm)
Display area
476.064 mm (H) x 267.786 mm (V) 527.04 mm (H) x 296.46 mm (V) 597.888 mm (H) x 336.312 mm (V)
Pixel Pitch
0.24795 mm (H) x 0.24795 mm (V) 0.2745 mm (H) x 0.2745 mm (V) 0.3114 mm (H) x 0.3114 mm (V)
Maximum Pixel Clock
174.5 MHz 174.5 MHz 174.5 MHz
Power Supply
AC100-240V~ 50/60Hz
Based on the AC voltage of the adapter. For the DC voltage of the product, refer to the product label.
Signal connectors
HDMI, D-SUB
Environmental conditions Operating
Temperature: 10 °C – 40 °C (50 °F – 104 °F)
Humidity: 10 % – 80 %, non-condensing
Storage
Temperature: -20 °C – 45 °C (-4 °F – 113 °F)
Humidity: 5 % – 95 %, non-condensing
