9
Preparations
Chapter 02
Installation
Attaching the Stand
―
Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
The product is curved. Placing pressure on the product when on a flat surface may damage the product. When the product is on the ground facing up or down, do not put pressure on it.
1
2
3
Insert the stand neck into the stand
base in the direction shown in the
figure.
Turn the stand neck 180° into normal
position.
Align the stand with the stand neck
guide and then turn the screw on the
bottom of the stand to fix the stand.
4
4
5
6
Place the protective Styrofoam
(cushion) included in the package on
the floor and place the product facing
down on the Styrofoam, as shown in
the image. If Styrofoam is unavailable,
use a thick sitting mat.
Hold the main body of the product
with your hand as shown by the figure.
Push the assembled stand into the
main body in the direction of the
arrow as shown in the figure.
Connect the power supply and the
signal cable as shown in the figure.
Caution
Do not arbitrarily remove the panel
film. If not observed, the warranty
service may be restricted.
To Next Page
