Disassemblr and Reassembly
4-1-2 Ass’y Case Top Removal
1
Remove ass'y case top by gentlely releasing
2 locking tabs with a small screw driver.
(see DETAIL "A")
REASSEMBLY : Put the 7 tabs into the slot,
while sliding it as shown in DETAIL "B".
2 locking tabs
Precision screw driver
< DETAIL "A" >
"B"
< DETAIL "B" >
Fig. 4-2 Ass’y Case Top Removal
*
You don’t need to disassemble the Case Top except that
you change the Deck Mechanism.
