Samsung Electronics 4-11
Disassemblr and Reassembly
4-2 Circuit Boards Location
ASS'Y MAIN BOARD
ASS'Y CCD BOARD
ASS'Y LCD BOARD
ASS'Y FUNCTION BOARD
ASS'Y EVF BOARD
ASS'Y REAR BOARD
ASS'Y EIS BOARD (EIS MODEL)
ASS'Y FRONT BOARD (NON EIS MODEL)
Fig. 4-11 Circuit Boards Location
