Samsung Electronics5-2
Alignment and Adjustment
POSITION
IC601 IC601 IC601
ACTION MODE
28PIN 27PIN 26PIN
L H H EJECT
L L H UNLOADING STOP
H L L LOADING STOP
H H L PLAY, FF, Z/RTN, STILL....
EJECT
UNLOADING STOP
LOADING STOP
PB
IC601
27PIN
GROUND
IC601
26PIN
COMMON
IC601
28PIN
OPEN
EJECT
PLAY
LOADING
STOP
UNLOADING
STOP
LOADING
UNLOADING
Reference
¥ Mechanical Transition Chart of MODE switch.
