NO-OSD-DISPLAY
ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 0)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
056 5A 54 68 4E changed by AUTO AWB ADJ(0CF) B CONTROL 5100K
057 00 00 00 00 @DSP#12C( HAPGN) at AGC
058 00 00 00 00 @DSP#12C (HAPGN) at AGC
059 03 03 03 03 "* AWB- RATIO ; 1/3 CENTER TRACKING"
05A 03 03 03 03 "* AWB- RATIO HIGH ; CENTER AXIS OVER 5100K(OUTDOOR)"
05B 04 04 04 04 "* AWB- RATIO LOW ; CENTER AXIS BELOW 3100K(INDOOR)"
05C E0 E0 E0 E0 SHUTTER START POINT OF IRIS CONTROL PERCENT(FF=100% IRIS MAX)
05D 80 80 80 80 "@WDR ON; AE DATA CUTTING -LOW"
05E 02 02 02 02 "@WDR ON; AE DATA CUTTING -HIGH"
05F 50 50 50 50 "@WDR ON; BLACK BALANCE MAX-DATA (MIN DATA+31)"
060 40 40 40 40 "@WDR ; AE-TARGET MARGIN; #087,#088 -#060, AT CLIP-COUNTER ON "
061 10 10 10 10 "@WDR ; CLIP_COUNTER-TH-'HIGH' BYTE "
062 15 15 15 15 @EIS H-TH-COUNTER
063 35 35 35 35 @EIS H-TH
064 15 15 15 15 @EIS V-TH-COUNTER
065 35 35 35 35 @EIS V-TH
066 08 08 04 04 "@WDR ON; Y ,C GAMMA 1 "
067 0D 0D 07 07 "@WDR ON; Y ,C GAMMA 2 "
068 1B 1B 15 15 "@WDR ON; Y,C GAMMA 3 "
069 32 32 2C 2C "@WDR ON; Y ,C GAMMA 4 "
06A 57 57 4D 4D "@WDR ON; Y,C GAMMA 5 "
06B 82 82 70 70 "@WDR ON; Y,C GAMMA 6"
06C C0 C0 B4 B4 "@WDR ON; Y ,C GAMMA 7"
06D F0 F0 F8 F8 "@WDR ON; Y,C GAMMA 8"
06E EE EE EE EE "@WDR ON; ADDR#12C ;YVBKT,YVBK,HBLK,YHBK"
06F 08 08 08 08 "@WDR ON; ADDR#123;YHPSC,YAPC"
070 50 50 50 50 "@WDR ON; ADDR#126;YLPFSEL"
071 10 10 10 10 "@WDR ON; ADDR#134;RED DARK SLICE"
072 03 03 03 03 "@WDR ON; ADDR#135;BLUE DARK SLICE"
073 00 00 00 00 "@WDR ON; ADDR#136;GREEN DARK SLICE"
074 11 11 10 10 @CINEMA F-ZONE LIMIT UP
075 7D 7D 68 68 @CINEMA F-ZONE LIMIT UP
076 5A 60 4B 50 @R-GAIN POSITIVE(ADDR.147) at OUTDOOR
077 55 60 3D 4A @R-GAIN NEGATIVE(ADDR.148) at OUTDOOR
078 25 2C 12 29 @R-HUE POSITIVE (ADDR.149) at OUTDOOR
079 28 3B 17 35 @R-HUE NEGATIVE (ADDR.14A) at OUTDOOR
07A 33 39 2C 31 @B-GAIN POSITIVE(ADDR.14B) at OUTDOOR
07B 2B 30 1D 21 @B-GAIN NEGATIVE(ADDR.14C) at OUTDOOR
Samsung Electronics 5-7
Alignment and Adjustment
