NO-OSD-DISPLAY
ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 0)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
07C 1C 1A 24 26 @B-HUE POSITIVE (ADDR.14D) at OUTDOOR
07D 0E 0E 15 0D @B-HUE NEGATIVE (ADDR.14E) at OUTDOOR
07E 50 50 50 50 @NEGA BLC TARGET-'L'
07F 00 00 00 00 @NEGA BLC TARGET-'H'
080 04 04 04 04 "@AE; AE A-WINDOW WEIGHT '05'=50%"
081 5E 5E 5E 5E "@AE; SPOTLIGHT AE-TARGET 'L'"
082 00 00 00 00 "@AE; SPOTLIGHT AE-TARGET 'H'"
083 90 90 90 90 @DIGITAL CLAMP CONTROL START AGC
084 0C 0C 0C 0C @AGC MAX , DIGITAL CLAMP CONTROL(ADDR.#118)
085 90 90 90 90 * AWB- W/B DATA-TH
086 02 02 02 02 * AWB- LUMINANCE AREA NUMBER
087 00 00 00 00 "@AE; BLC/WDR , AE TARGET 'L'"
088 02 02 02 02 "@AE; BLC /WDR, AE TARGET 'H'"
089 75 75 75 75 @SEPIA CDS-R
08A 3A 3A 3A 3A @SEPIA CDS-G
08B 00 00 00 00 "@AE; SAND&SNOW MODE AE TARGET 'L'"
08C 02 02 02 02 "@AE; SAND&SNOW MODE AE TARGET 'H'"
08D 00 00 00 00 changed by AUTO 3MLENS ADJ(0DE) @FOCUS TELE MARGIN LOW BYTE(CANON X22 LENS)
08E 00 00 00 00 changed by AUTO 3MLENS ADJ(0DE) @FOCUS TELE MARGIN HIGH BYTE(CANON X22 LENS)
08F F0 F0 F0 F0 changed by AUTO 3MLENS ADJ(0DE) @FOCUS WIDE MARGIN LOW BYTE(CANON X22 LENS)
090 FF FF FF FF changed by AUTO 3MLENS ADJ(0DE) @FOCUS WIDE MARGIN HIGH BYTE(CANON X22 LENS)
091 F8 09 00 0A @CCD H-PIXEL NUMBER -LOW BYTE
092 02 02 03 02 @CCD H-PIXEL NUMBER -HIGH BYTE
093 23 23 F7 F7 @CCD V LINE NUMBER -LOW BYTE
094 01 01 00 00 @CCD V LINE NUMBER -HIGH BYTE
095 1C 0C 16 09 @CCD V SKIP LINE DEFAULT VALUE
096 B9 46 50 EE @CCD V LINE NUMBER LOW BYTE
097 02 02 02 01 @CCD V LINE NUMBER HIGH BYTE
098 98 98 98 98 "@DSP IC ADDR #41H ;ART DSE LEVEL"
099 B8 B8 B8 B8 "@DSP IC ADDR #1CH ;NEGA MODE WHITE CLIP LEVEL"
09A 30 30 30 30 * AWB- START HALL VALUE
09B 1C 1C 1C 1C "@DSE- MOSAIC SIZE; DSP IC ADDR #39H "
09C F4 F4 F4 F4 "@D/ZOOM MAX RATIO; CO=4X, EE=14.3X, F4= 20X "
09D 68 68 68 68 @ NOISE SLICE START AGC VALUE
09E 0B 0B 0B 0B @ HAP(DSP #10BH) MIN VALUE AT AGC MAX
09F 0B 0B 0B 0B @ VAP(DSP 310C) MIN VALUE AT AGC MAX
0A0 18 20 18 20 @ YAP(DSP #10DH) MAX VALUE AT AGC MAX
0A1 A0 A0 A0 A4 @ CHROMA SUPPRESS PERCENT
Samsung Electronics5-8
Alignment and Adjustment
