NO-OSD-DISPLAY
ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 0)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
0A2 60 60 60 60 @ CHROMA SUPPRESS START AGC VALUE
0A3 00 00 00 00 changed by AUTO IRIS ADJ(0CE) @ IRIS CONTROL MAX LOW BYTE
0A4 05 05 05 05 changed by AUTO IRIS ADJ(0CE) @ IRIS CONTROL MAX HIGH BYTE
0A5 B4 B4 B4 B4 * AWB -AT OUTDOOR,TRACKING AMOUNT(IN CASE,INDOOR DATA INPUT) ,B4=70%,FF=0%(NO TRACKING)
0A6 C0 C0 C0 C0 * AWB- WB AGC% , STOP POINT ( 80=50%, C0=75%)
0A7 89 89 89 89 @HALL WIDTH AT HALL ADJUST
0A8 E5 E5 E5 E5 changed by AUTO 3MLENS ADJ(0DE) @ZOOM RESET LOW(16X, 22X LENS)
0A9 88 88 88 88 changed by AUTO 3MLENS ADJ(0DE) @ZOOM RESET HIGH(16X, 22X LENS)
0AA 80 80 80 80 changed by ZOOM VR CENTER(0D6) @ZOOM VR CENTER VALUE
0AB 20 20 20 20 @ZOOM VR CENTER MARGIN( ZOOM STOP PERIOD)
0AC 34 30 34 30 changed by AUTO AGC ADJ(0DB) @AGC MIN VALUE
0AD A8 A8 A8 A8 changed by AUTO AGC ADJ(0DB) @AGC MAX VALUE
0AE 0B 0B 09 09 "REMOCON ZOOM SPEED; 22X LENS -PAL:0B NTSC:09 "
0AF 02 02 02 02 AF ZIGZAG AMOUNT AT BASIC ZOOM SPEED
0B0 68 28 5B 30 @IN AGC AUTO ADJUST (ADDR.0DB), SHUTTER CONTROL OF AGC MIN ADJUST OPERATING(D0='0'FIX)
0B1 2A 2B 08 01 @IN AGC AUTO ADJUST (ADDR.0DB), SHUTTER CONTROL OF AGC MAX ADJUST OPERATING(D7='1'FIX)
0B2 ~0B6 ~0B6 ~0B6 ~0B6 NO USED
0B7 1A 1A 16 16 "ZOOM MAX SPEED ;22X LENS PAL:19H,NTSC:15H"
0B8 3A 3A 3A 3A @HALL REF START, AT AUTO HALL ADJUST ADDR.0CD
0B9 4C 4C 4C 4C @HALL GAIN START, AT AUTO HALL ADJUST ADDR.0CD
0BA 40 40 40 40 changed by AUTO HALL ADJ(0CD) @HALL MIN VALUE
0BB C0 C0 C0 C0 changed by AUTO HALL ADJ(0CD) @HALL MAX VALUE
0BC E0 D0 D0 D0 @AE TARGET-LOW BYTE
0BD 00 00 00 00 @AE TARGET-HIGH BYTE
0BE B0 B0 B0 B0 changed by AUTO IRIS ADJ(0CE) @IRIS CONTROL MIN LOW BYTE
0BF 09 09 09 09 changed by AUTO IRIS ADJ(0CE) @IRIS CONTROL MIN HIGH BYTE
0C0 18 18 18 18 changed by AUTO 3MLENS ADJ(0DE) @FOCUS RESET LOW(16X,22X LENS)
0C1 82 82 82 82 changed by AUTO 3MLENS ADJ(0DE) @FOCUS RESET HIGH(16X,22X LENS)
0C2 40 40 40 40 @HALL CLOSE TARGET
0C3 ~C6 ~C6 ~C6 ~C6 NO USED
0C7 12 12 12 12 EIS GYRO-RESET TIME '0C=3.7SEC'
0C8 13 13 13 13 EIS START TIME ('10'=4.4SEC) AFTER EIS GYRO-RESET
0C9 65 64 65 60 @IRIS CONTROL OF ZOOM WIDE POSITION AT LENS ADJUSTMENT
0CA 24 24 24 24 @QB_GCTRL
0CB 48 48 48 48 @AETAR L (FLEX-ZONE)
0CC 00 00 00 00 @AETAR H (FLEX-ZONE)
0CD FF FF FF FF @@HALL AUTO ADJUST
0CE FF FF FF FF @@IRIS AUTO ADJUST
Samsung Electronics 5-9
Alignment and Adjustment
