NO-OSD-DISPLAY
ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 0)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
0CF FF FF FF FF @@W/B AUTO ADJUST
0D0 FF FF FF FF @@LENS AUTO INFINITE ZOOM TRACK(DON'T USE IN SERVICE FIELD)
0D1 68 68 A0 A0 FIND AGC ADJUST TARGET SHUTTER CONTROL AT AGC AUTO ADJUST (ADDR.0DB)
0D2 ~0D5 ~0D5 ~0D5 ~0D5 NO USED
0D6 FF FF FF FF @@ZOOM VR LEVER CENTER FINDING
0D7 01 01 01 01 @@ZOOM/FOCUS CHK=ONE AF ENABLE BIT 00~03
0D8 ~0DA ~0DA ~0DA ~0DA NO USED
0DB FF FF FF FF @@AGC AUTO ADJUST (ADDR. 0B0,0B1,0D1,0AC,0AD)
0DC FF FF FF FF "@LENS ZOOM TRACK CHECKING ;CONFIRM,DATA UP,DOWN KEY"
0DD FF FF FF FF NO USED
0DE FF FF FF FF "@@LENS 3M ZOOM TRACK ADJUST =SERVICE FIELD MODE (KEEP DISTANCE; 3M+/-1Cm)"
0DF A0 A0 A0 A0 @EEPROM -TABLE -INITIAL ('99'+CONFIRM =CAMERA ONLY, 'AA'+CONFIRM=CAM+VCR INITIAL)
0E0 ~0FF ~0FF ~0FF ~0FF VCR ADDRESS & DATA
Samsung Electronics5-10
Alignment and Adjustment
