ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 1)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
100 00 00 00 00 EMODE(2:0)='000'internal reset VSKIP='0' CINEMA ='0' ND TEST DSYNC JITNSYNC
101 A0 A0 A0 A0 ADCK FWCK SCK LALT HSP DOSEL H_MAX_SEL(1:0)
102 C0 C0 C0 C0 SHTR='11' HSS H2DEL(3:0) 0~15nSEC DELAY ADJUST PBLK_SEL HSSC(8)
103 00 00 00 00 |---- HIGH SHUTTER SPEED CONTROL (8:0) ----|
104 0D 19 0D 19 |---- GHDLY(7:0) -128 ~+ 127 ----|
105 07 03 06 03 |---- H1DLY[3:0] 0~+15nS ----| |---- RGDLY[3:0] -8~+7nS ----|
106 50 48 4E 38 |---- SHP_DLY[3:0] -8~+7nS |---- SHD_DLY[3:0] -8~+7nS ----|
107 70 40 50 40 FLALTSEL ADCKDLY[2:0] 0~+7nS DSCKSEL FWCKDLY[2:0] 0~+7nS
108 0D 0D 0D 0D |---- HCNTSET[7:0] ----|
109 00 00 00 00 |---- LSSC[7:0] low speed shutter ----|
10A 00 00 00 00 DCKSEL |---- VCNTSET[6:0] ----|
10B 0D 0D 0D 0D * WDR-AF CLIMB NOISE THRESHOLD
10C 50 50 50 50 * WDR-AF CENTER DATA THRESHOLD LOW
10D 01 01 01 01 * WDR-AF CENTER DATA THRESHOLD HIGH
10E 0C 0C 0C 0C * WDR-AF PEAK NOISE THRESHOLD LOW
10F 09 09 09 09 * WDR-AF PEAK NOISE THRESHOLD HIGH
CLUSTER 1 (HEADER[3:0] = 4'b0001) ENCODER/ DEFECT COMPENSATION
110 50 52 50 52 |---- C-SYNC[7:0] c.sync level 0~255 ----|
111 01 01 01 03 |---- SETUP[7:0] setup level 0~255 ----|
112 00 00 00 00 |---- EBURST[7:0] burst phase control :NTSC only ----|
113 50 10 50 10 FSC4 EYDLY[2:0]000=-4PCK,111=+3PCK UV_CTRL |---- EBURST_H[2:0] ----|
114 D8 D8 C8 CC |---- EUSC[7:0] "-128~+127 ;B-Y BURST VALUE" ----|
115 28 28 00 00 |---- EVSC[7:0] "-128~+127 ;R-Y BURST VALUE" ----|
116 00 00 00 00 X X X X X NOTBC EXTDAC PD1
117 03 03 03 03 X X AD[1:0] AD CLK DLY D-CLP S2 S1 S0
118 0D 10 0E 10 |----- CLAMP_OFFSET[7:0] ----|
119 40 40 40 40 |----- DEFECY_THRESHOLD[7:0] 0~255 ----|
11A 00 00 00 00 X X X X RAM-OUT |---- RAM-OUT[8:6]
11B 00 00 00 00 |---- RAM-OUT[5:0] ----| RAM-OUT[9:8]
11C 00 00 00 00 |---- RAM-OUT[7:0] ----|
11D 00 00 00 00 X |---- PFINDCNT[5:0] ----|
11E 0E 0A 0A 0A * AWB- AREA INTERVAL FORM CENTER AXIS
11F 03 03 03 03 LENS HYSTERESIS ZOOM TRACKING CURVE
CLUSTER 2 (HEADER[3:0] = 4'b0010) LUMINANCE
120 66 66 66 66 "YVBKTH[1;0]" YVBKG[1:0] "YHBKTH[1;0]" YHBKG[1:0]
121 D9 0C D9 10 Y_H_GAIN[1:0] X |---- Y_H_POSI_GAIN[4:0] ----|
122 94 54 94 4D Y_L_GAIN[1:0]
YOLD-GAMMA
|---- Y_V_POSI_GAIN[4:0] ----|
Samsung Electronics 5-11
Alignment and Adjustment
ÒCAMERA ADJUST MODE, EEPROM ADDRESS SEQUENCE & DATA OF PAGE 1Ó
To Next Page
