ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 1)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
123 01 03 01 03 X X |---- YA_NOISE_SLICE[5:0] ----|
124 98 78 A0 78 |---- YHL_SC[7:0] ----|
125 37 37 37 37 |---- YEDGE_SC[7:0] ----|
126 50 50 50 50 X YVAPPSEL YEGCS
YHLCS'0'=ON
YLPFSEL |---- "YSCDLY[2;0]" ----|
127 0A 30 0A 30 |---- YHINS[6:0] aperture noise slice level after gamma correction. ----| YNEGA/POSI
128 E4 E8 E4 E0 |---- YWC[7:0] ----|
129 84 8A 84 8A |---- YGAIN[7:0] X0~X2 ----|
12A 00 00 00 00 X YENHANTH[2:0] X X YENHANG[1:0]
12B 08 08 08 08 |---- YART[2:0] ----| |---- YHI-A-GAIN[1:0] ----|
12C AF 6E AF 7F |---- HAPGN[4:0] ----| YHCLIP[3:2] H_C_SUP[4]
12D 81 81 81 81 |---- VAPGN[4:0] ----| YHCLIP[1:0] E_C_SUP[4]
12E 88 B8 88 B8 H_C_SUPP_GAIN[3:0]high light color suppress F_FALL[3:0] edge color suppress
12F 58 50 50 50 |---- Y_APERTUTR_CLIP[7:0] ----|
CLUSTER 3 (HEADER[3:0] = 4'b0011) LUMINANCE & CHROMA
130 2B 2B 2B 2B YHPEG[1:0] YVPEG[1:0] YHEMBSEL[1:0] YVEMBSEL[1:0]
131 30 30 30 30 |---- YPST[7:0] pastel level ----|
132 30 30 30 30 |---- YEMB[7:0] embossing level ----|
133 00 00 00 00 X X X X YEMBOSS YPASTEL YIN-OUT YWINDOW
134 04 06 05 05 |---- CRDS[7:0] r-dark-slice ----|
135 00 03 FE 04 |---- CBDS[7:0] b-dark-slice
136 FD 00 00 00 |---- CGDS[7:0] g-dark-slice
137 31 34 53 34 |---- CRWB[7:0] R-white-balance-control
138 A0 8C 8F A0 |---- CBWB[7:0] B-white-balance-control
139 24 24 24 24 |---- CGWB[7:0] G-white-balance-control
13A 07 07 07 07 |---- "CSLOPE1[7:0]COLOR_KEY_SLOPE_1;-64~+64"
13B E6 E6 E6 E6 |---- "CSLOPE2[7:0]COLOR_KEY_SLOPE_2;-64~+64"
13C 29 29 29 29
"COLOR KEY OPTION :0(RED)~4;13A,13B,13C ADDRESS"
CSLOPE1 H[9] CSLOPE1 H[8] CSLOPE2 H[9] CSLOPE2 H[9]
13D 00 00 00 00 X X X CNEGA CBAR CMONO CKEY CKEY-NEGA
13E FF FF FF FF DUMMY
13F FF FF FF FF DUMMY
CLUSTER 4 (HEADER[3:0] = 4'b0100) CHROMA
140 17 07 17 37 X X
CHCON(S1/S2)
CVCON(cr/cb)
CYLSEL CRMS CBMS C-GAMMA-SEL
141 42 42 42 42 |---- CRCOEF[7:0] cr-matrix-coefficient ----|
142 66 66 66 66 |---- CBCOEF[7:0] cr-matrix-coefficient ----|
143 59 59 59 59 |---- CRRG[7:0] R-G signal coeff. for R-Y signal creating. ----|
144 D9 D9 D9 D9 |---- CBRG[7:0] R-G signal coeff. for B-Y signal creating. ----|
145 F2 F2 F2 F2 |---- CRBG[7:0] B-G signal coeff. for R-Y signal creating. ----|
146 72 72 72 72 |---- CBBG[7:0] B-G signal coeff. for B-Y signal creating. ----|
147 70 76 6C 67 |---- CRYGP[7:0] R-Y GAIN CONTROL + ----|
Samsung Electronics5-12
Alignment and Adjustment
