ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 1)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
148 78 7E 60 70 |---- CRYGN[7:0] R-Y GAIN CONTROL - ----|
149 1D 1D 19 20 |---- CRYHP[7:0] R-Y HUE CONTROL + ----|
14A 2A 29 1A 40 |---- CRYHN[7:0] R-Y HUE CONTROL - ----|
14B 3D 3E 33 34 |---- CBYGP[7:0] B-Y GAIN CONTROL + ----|
14C 33 35 24 24 |---- CBYGN[7:0] B-Y GAIN CONTROL - ----|
14D 50 3C 34 39 |---- CBYHP[7:0] B-Y HUE CONTROL + ----|
14E 08 04 23 0A |---- CBYHN[7:0] B-Y HUE CONTROL - ----|
14F 80 80 80 80 |---- CGAIN[7:0] x0~ x2 ----|
CLUSTER 5 (HEADER[3:0] = 4'b0101) GAMMA
150 08 08 04 04 |---- YG1[7:0] @Y GAMMA POINT 1 ----|
151 0D 0D 07 07 |---- YG2[7:0] @Y GAMMA POINT 2 ----|
152 1B 1B 15 15 |---- YG3[7:0] @Y GAMMA POINT 3 ----|
153 32 32 2C 2C |---- YG4[7:0] @Y GAMMA POINT 4 ----|
154 57 57 4D 4D |---- YG5[7:0] @Y GAMMA POINT 5 ----|
155 82 82 70 70 |---- YG6[7:0] @Y GAMMA POINT 6 ----|
156 C0 C0 B4 B4 |---- YG7[7:0] @Y GAMMA POINT 7 ----|
157 F0 F0 F8 F8 |---- YG8[7:0] @Y GAMMA POINT 8 ----|
158 06 04 04 04 |---- CGAMMA1[7:0] @C GAMMA POINT 1 ----|
159 0C 08 07 07 |---- CGAMMA2[7:0] @C GAMMA POINT 2 ----|
15A 1A 15 18 18 |---- CGAMMA3[7:0] @C GAMMA POINT 3 ----|
15B 2C 2B 30 30 |---- CGAMMA4[7:0] @C GAMMA POINT 4 ----|
15C 4C 4C 50 50 |---- CGAMMA5[7:0] @C GAMMA POINT 5 ----|
15D 78 78 78 78 |---- CGAMMA6[7:0] @C GAMMA POINT 6 ----|
15E B6 B6 B8 B8 |---- CGAMMA7[7:0] @C GAMMA POINT 7 ----|
15F F0 F0 F8 F8 |---- CGAMMA8[7:0] @C GAMMA POINT 8 ----|
CLUSTER 6 (HEADER[3:0] = 4'b0110) D.ZOOM & EIS
160 AE AE AE AE D.ZOOM ZOOM-BYPASS D.EFFECT VADJ[1:0] HADJ[1:0] Z_DELAY
161 00 00 00 00 |---- VZOOM[7:0] ----|
162 1C 0C 18 09 |---- VZSKIP[7:0] ----|
163 00 00 00 00 |---- VZOFFE[7:0] EVEN FIELD LINE OFFSET ----|
164 00 00 00 00 |---- VZOFFO[7:0] ODD FIELD LINE OFFSET ----|
165 2A 00 2A 00 |---- HZOOM[7:0] ----|
166 00 00 00 00 MOSAIC H-ADJ[1:0] X X X X X HZSTR[8]
167 3E 00 38 00 |---- HZSTR[7:0] ----|
168 09 00 AF 00 |---- HZOFS[7:0] ----|
169 00 00 00 00 |---- MOSAIC[5:0] 4d=8x8,5d=10x10,63d=126x126 ----| MOSAIC V-ADJ[1:0]
16A 02 02 03 02 FE MODE[1:0] 01=F,10=H.M X X X X FCM[9:8]
16B F8 09 00 0A |---- FCM[7:0] ----|
16C 01 01 01 01 X X X X X X HMIRROR[9:8]
