ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 1)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
191 1F 1F 1F 1F X X X |---- OBYTH[4:0] ----|
192 30 30 30 30 |---- "OAWBSL 1[7:0]; 0~15, R-Y/B-Y CHART SLOPE 1 FOR AWB" ----|
193 15 15 15 15 |---- "OAWBSL 2[7:0]; 0~15, R-Y/B-Y CHART SLOPE 2 FOR AWB" ----|
194 70 70 70 70 |---- "OAWBSL 3[7:0]; 0~15, R-Y/B-Y CHART SLOPE 3 FOR AWB" ----|
195 60 60 60 60 |---- "OAWBSL 4[7:0]; 0~15, R-Y/B-Y CHART SLOPE 4 FOR AWB" ----|
196 20 20 20 20 |---- "OAWBSL 5[7:0]; 0~15, R-Y/B-Y CHART SLOPE 5 FOR AWB" ----|
197 05 05 05 05 |---- "OAWBSL 6[7:0]; 0~15, R-Y/B-Y CHART SLOPE 6 FOR AWB" ----|
198 34 34 34 34 X X |---- "OAWB_DETECT_R-Y_POINT A[5:0] ;0~63" ----|
199 1C 1C 1C 1C X X |---- "OAWB_DETECT_R-Y_POINT B[5:0] ;0~63" ----|
19A 18 18 18 18 X X |---- "OAWB_DETECT_R-Y_POINT C[5:0]; 0~63" ----|
19B 28 28 28 28 X X |---- "OAWB_DETECT_R-Y_POINT D[5:0] ;0~63" ----|
19C 18 18 18 18 X X |---- "OAWB_DETECT_B-Y_POINT A[5:0] ;0~63" ----|
19D 28 28 28 28 X X |---- "OAWB_DETECT_B-Y_POINT B[5:0] ;0~63" ----|
19E 1E 1E 1E 1E X X |---- "OAWB_DETECT_B-Y_POINT C[5:0]; 0~63" ----|
19F 16 16 16 16 X X |---- "OAWB_DETECT_B-Y_POINT D[5:0] ;0~63" ----|
CLUSTER 10 (HEADER[3:0] = 4'b1010) AF DATA1
1A0 03 03 03 03 * AF CENTER AREA DATA SHIFT COEFF. ----|
1A1 02 02 02 02 * AF ALL AREA DATA SHIFT COEFF. ----|
1A2 C0 C0 C0 C0 * AF ALL AREA FILTER1 DATA CUTTING LEVEL-LOW ----|
1A3 01 01 01 01 * AF ALL AREA FILTER1 DATA CUTTING LEVEL-HIGH ----|
1A4 00 00 00 00 * AF ALL AREA FILTER2 DATA CUTTING LEVEL-LOW ----|
1A5 01 01 01 01 * AF ALL AREA FILTER2 DATA CUTTING LEVEL-HIGH ----|
1A6 A0 A0 A0 A0 * AF CENTER AREA FILTER1 DATA CUTTING LEVEL-LOW. ----|
1A7 00 00 00 00 * AF CENTER AREA FILTER1 DATA CUTTING LEVEL-HIGH ----|
1A8 80 80 80 80 * AF CENTER AREA FILTER2 DATA CUTTING LEVEL-LOW. ----|
1A9 00 00 00 00 * AF CENTER AREA FILTER2 DATA CUTTING LEVEL-HIGH ----|
1AA 18 18 18 18 * AE VARIATION THRESHOLD FOR AF ----|
1AB 20 20 20 20 * AF INITIAL DATA STABLE COEFF. ----|
1AC 0A 0A 0A 0A * AF CLIMB NOISE THRESHOLD
1AD 16 16 16 16 * AF CLIMB SPEED DOWN THRESHOLD1
1AE 10 10 10 10 * AF CLIMB DATA VARIATION THRESHOLD
1AF 80 80 80 80 * AF PEAK CHECKING THRESHOLD
CLUSTER 11 (HEADER[3:0] = 4'b1011) ,AF DATA2
1B0 10 10 10 10 * AF ZIGZAG NOISE THRESHOLD1 ----|
1B1 23 23 28 28 * AF ZIGZAG CHECKING TIME1 ----|
1B2 30 30 30 30 * AF ZIGZAG NOISE THRESHOLD2 ----|
1B3 32 32 3C 3C * AF ZIGZAG CHECKING TIME2 ----|
1B4 20 20 20 20 * AF ZIGZAG NOISE THRESHOLD3 ----|
1B5 08 08 08 08 * AF PEAK CONFIRM THRESHOLD1 ----|
Samsung Electronics 5-15
Alignment and Adjustment
