ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 1)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
1B6 07 07 07 07 * AF PEAK CONFIRM CONTINUE COUNT ----|
1B7 1F 1F 1F 1F * AF PROGRAM OPTION1 ----|
1B8 18 18 18 18 * AF CENTER AREA AGC CUTTING PERCENT ----|
1B9 30 30 30 30 * AF ALL AREA AGC CUTTING PERCENT ----|
1BA 16 16 16 16 * AF CLIMB SPEED DOWN THRESHOLD2 ----|
1BB 14 14 14 14 * AF PEAK CLIMB RATIO ----|
1BC 10 10 10 10 * AF CENTER AREA CUTTING DATA FOR PATROL-LOW
1BD 10 10 10 10 * AF OPTION2
1BE 20 20 20 20 * AF ALL AREA CUTTING CUTTING DATA FOR PATROL-LOW
1BF 00 00 00 00 * AF ALL AREA CUTTING CUTTING DATA FOR PATROL-HIGH
"CLUSTER 12 (HEADER[3:0] = 4'b1100); AWB/AE"
1C0 1E 1E 1E 1E * AF PEAK CONFIRM SPEED UP RATIO
1C1 25 25 25 25 * AE AUTO MODE CONTROL SPEED DOWN RANGE ----|
1C2 40 40 40 40 * AE SPOTLIGHT MODE CONTROL SPEED DOWN RANGE ----|
1C3 04 04 04 04 * AE AUTO MODE CONTROL SPEED DOWN REFERENCE ----|
1C4 10 10 10 10 * AWB CUTTING THRESHOLD1 ----|
1C5 10 10 10 10 * AWB CUTTING THRESHOLD2 ----|
1C6 40 40 40 40 * AWB CUTTING THRESHOLD3 ----|
1C7 40 40 40 40 * AWB CUTTING THRESHOLD4 ----|
1C8 00 00 00 00 * AWB CUTTING THRESHOLD15 ----|
1C9 24 24 24 24 * AE OFFSET BORDER ----|
1CA 0C 0C 0C 0C * AE SPEED OFFSET COUNTER ----|
1CB 6A 60 6A 60 * AWB HALL STOP AT SPOTLIGHT MODE ----|
1CC 8A 80 8A 80 * AWB HALL AT EIS MODE ----|
1CD F0 F0 F0 F0 * AWB HALL STOP AT SPORTS MODE ----|
1CE F0 F0 F0 F0 * AWB HALL AT PORTRAIT MODE
1CF F0 F0 F0 F0 * AWB HALL AT SAND&SNOW MODE
"CLUSTER 13 (HEADER[3:0] = 4'b1101); DECODER 1"
1D0 ~1FC ~1FC ~1FC ~1FC FIXED ----|
1FD ~1FF ~1FF ~1FF ~1FF MICOM VERSION
