Samsung SCL810 - Page 19

Samsung Electronics1-18
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
78C 22 22 22 22 ;TRIC DO DETECTION LEVEL
78D 3B - - - ;PB DO DETECTION LEVEL
78E FF - - - ;FCNR/C DEEMPHA/C EMPHA LIMITER
78F FB - - - ;PB_C ENHANCER/CNR/C GAINSETTINGCLIP
790 B8 - - - ;PB BLUE BACKSIGNAL B-Y LEVEL
791 6E - - - ;PB BLUE BACKSIGNAL R-Y LEVEL PB B-Y BURST LEVEL
792 59 59 64 64 ;ffapc B-Y BURST LEVEL PB R-Y BURST LEVEL
793 80 80 9C 9C ;ffapc R-Y BURST LEVEL
794 15 - - - ;TBC SYNC LEVEL
795 AC - - - ;TBC LB °§H B SYNC CUT LEVEL
796 59 59 64 64 ;TBC B-Y BURST LEVEL PB B-Y BURST LEVEL
797 80 80 9C 9C ;TBC R-Y BURST LEVEL PB R-Y BURST LEVEL
ADDR MODEL/DATA CONTENT APPLY MODELS
NTSC PAL
HI8 NOR HI8 NOR
001 C6 C6 C6 OPTION(DIS MODEL) VP-L850/VP-L850D/VP-L870/SCL860/SCL870
46 46 OPTION(NON-DIS MODEL) VP-L800/VP-L800U/SCL810
021 08 08 08 AGC ON H ENHANCER VP-L850/VP-L850D/VP-L870/SCL860/SCL870
05 05 AGC ON H ENHANCER VP-L800/VP-L800U/SCL810
031 08 08 08 AGC ON H CORE LEVEL VP-L850/VP-L850D/VP-L870/SCL860/SCL870
05 05 AGC ON H CORE LEVEL VP-L800/VP-L800U/SCL810
032 08 08 08 AGC ON V CORE LEVEL VP-L850/VP-L850D/VP-L870/SCL860/SCL870
05 05 AGC ON V CORE LEVEL VP-L800/VP-L800U/SCL810
CHANGED DATA BY MODEL
