Samsung Electronics 2-9
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
172 AD64-00703E CASE-EVF R, ABS94VO, EVF
252 AD64-00450M CASE-EVF L;ABS94VO D/GRY VE0812 G6238 ALL
253 AC61-32047A PLATE-NUT;SPTE T0.8 ALL
262 AD97-02441A ASSY-EVF LENS
269 AD97-06589A ASSY-CASE EVF R
271 AD73-00040A RUBBER-EVF CUP
273 AD66-00105A LINK-EVF;POM BLK ALL
274 AD66-00106A LINK-LOCK;ABS 94HB BLK ALL
275 AD64-00458A LOCKER-EVF;POM BLK ALL
276 AD61-00104A GUIDE-PLATE;SPTE T0.8 ALL
277 AD61-00297A SHAFT-EVF;SUS303 ALL
300 AD97-04455A ASSY-UNIT EVF;0.24”,NTSC
904 AC60-10055A SCREW-TAPPING;M2X4 FZB ALL
905 AC60-10054A SCREW-TAPPING;M2X6,FZB ALL
915 AC60-10043A SCREW-TAPPING;1.7X6,FZB
