Samsung Electronics 2-13
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
230 AD64-00757A INLAY-DIGITAL;PVC SHEET
281 AD07-00027A PVI LCD;NTSC
282 AD97-02233A ASSY-BACK LIGHT;ASSY,M2, CASIO
283 AD97-04458A ASSY-LCD BOARD;NTSC
284 AD64-00758G CASE-LCD TOP;ABS 94 VO
285 AD64-00464B CASE-LCD BOTTOM;ABS94VO NTSC (COLOR)
286 AD63-00188G COVER-HINGE TOP;ABS 94HB
287 AD63-00190A COVER-HINGE BOTTOM;ABS 94HB
288 AD64-00445A BUTTON-LCD LOCK;PC/ABS
289 AD64-00446A BUTTON-LCD REVERSE;ABS 94HB
290 AD61-00585A GUIDE-LCD LOCK;POM BLK
291 AD61-12033A BRKT-NUT;SECC T0.8
292 AD61-00344A SPRING-LCD LOCK;SWPB
293 AD61-00627A SPRING-LCD REVERSE;SUS304 WPB
294 AD97-02487A ASSY-HINGE;ASSY
913 AC60-10019A SCREW-MACHINE;M2X4 FZB
914 AC60-10028A SCREW-MACHINE;M1.7X3 FZB
915 AC60-10043A SCREW-TAPPING;TAP1.7X6 FZB
916 AC60-12128A SCREW-TAPPING;TAP1.7X4 FEB
917 6001-001291 SCREW-MACHIN;M1.7X4 FZB
