Samsung Electronics 2-15
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
123 AD63-00065C COVER-LI BATTERY
201 AD63-00315U COVER-LEFT(W6);ABS94HB HG0760 G6238 SCL810
AD63-00315V COVER-LEFT(W6);ABS94HB HG0760 G6238 SCL860
AD63-00315W COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L870
AD63-00469A COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L800U
AD63-00469B COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L800
AD63-00469C COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L850
AD63-00469D COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L850D
AD63-00469E COVER-LEFT(W6);ABS94HB HG0760 G6238 VP-L870
AD63-00315X COVER-LEFT(W6);ABS94HB HG0760 G6238 VM-C300
AD63-00315Y COVER-LEFT(W6);ABS94HB HG0760 G6238 VM-C360
AD63-00315Z COVER-LEFT(W6);ABS94HB HG0760 G6238 VM-C370
202 AD64-70085A BADGE-SAMSUNG(30);AL (30mm)
203 AD64-00753A BUTTON-EASY(W4);ABS94HB NTR
204 AD64-00427A BUTTON-FUNCTION(W2);ABS94HB HF0660I G3532
205 AD61-00600A HOLDER-LOCK EVF;POM BLK
206 AD61-00594A RAIL-EVF;POM BLK
207 AD61-00595A RAIL-LOCK;ABS 94HB BLK
210 AD97-04405A ASSY-CASE LEFT(W4);W4-PJ, LIGHT(X) VP-L800U/L800
AD97-04406A ASSY-CASE LEFT(W4);W4-PJ, LIGHT(O) SCL810/SCL860/SCL870
VP-L850/L850D/L870
211 AD64-00751A CASE-LEFT(W4);W4-PJ, LIGHT(X) VP-L800U/L800
AD64-00751B CASE-LEFT(W4);W4-PJ, LIGHT(O) SCL810/SCL860/SCL870
VP-L850/L850D/L870
213 AD64-00706A BUTTON-TAPE EJECT;ABS94HB HF0660I G3532
214 AD64-00707A BUTTON-VCR;ABS94HB HF0660I G3532
215 AD64-00755A KNOB-DUMMY(W4);ABS94HB NTR
216 AD64-00235B BUTTON-FUNCTION-A(M2);ABS94HB HF0660I G3532
217 AD64-00240C KNOB-DIAL MENU(M2);ABS94HB HF0660I G3532
218 AD69-00045A PAD-LCD;SILICON
219 AD97-03290A ASSY-TRIPOD;PC G3532
222 AD73-10048A RUBBER-SPEAKER;RUBBER BLK
224 AD97-04508A ASSY-FUNCTION B'D(W6) VP-L800U/L800/SCL810
AD97-04464A ASSY-FUNCTION BOARD SCL860/SCL870
VP-L850/L850D/L870
227 AD97-00244A ASSY-SPEAKER;SC-L315C, 2816S
242 AD61-00581A BRACKET-HINGE
250 AD97-06646A ASSY-EVF,NTSC/B&W SCW80/SCL810/SCL860/SCL870
AD97-06930A ASSY-EVF,PAL/B&W VP-W80U/W80/W87/W87D
VP-L800U/L800/L850/L850D/L870
AD97-06956A ASSY-EVF,DOM/B&W VM-C300/C360/C370
AD97-06931A ASSY-CVF,NTSC/COL SCW87
AD97-06932A ASSY-CVF,DOM/COL VM-C170
903 AC60-10020A SCREW-MACHINE(2X5);BLK
905 AC60-10054A SCREW-TAPPING(2X6);W4-PJ
905 AC60-10054A SCREW-TAPPING(2X6);BLK
912 AC60-10073A SCREW -TAP PLAIN(2X6);W-PJ(CASE-L+ASSY-EVF)
