Samsung Electronics 2-19
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
101 AD68-06018A ASSY-MAIN BOARD VP-W80
AD68-06018B ASSY-MAIN BOARD VP-W87
AD68-06018C ASSY-MAIN BOARD VP-L800
AD68-06018D ASSY-MAIN BOARD VP-L850
AD68-06018E ASSY-MAIN BOARD VP-L870
AD68-06018F ASSY-MAIN BOARD SCW80
AD68-06018G ASSY-MAIN BOARD SCW87
AD68-06018H ASSY-MAIN BOARD SCL810
AD68-06018J ASSY-MAIN BOARD SCL870
AD68-06018K ASSY-MAIN BOARD VM-C170
AD68-06018L ASSY-MAIN BOARD VM-C300
AD68-06018M ASSY-MAIN BOARD VM-C370
AD68-06018N ASSY-MAIN BOARD SCL860
AD68-06018P ASSY-MAIN BOARD VM-C360
AD68-06018Q ASSY-MAIN BOARD VP-W80U
AD68-06018R ASSY-MAIN BOARD VP-W87D
AD68-06018S ASSY-MAIN BOARD VP-L800U
AD68-06018T ASSY-MAIN BOARD VP-L850D
112 AD97-03040A ASSY-ZOOM LENS;22X ALL
113 AD97-04856A ASSY-CCD
114 AD61-00576A BRACKET-LENS(22X)-180;SUS304 T0.5(22X) ALL
115 AD63-62008A SPACER-CCD;SILICON (Hi8) ALL
116 AD29-92001F FILTER-OLP;OG-BF455
120 AD61-00222A CHASSIS-TOP
121 AD61-00904A CHASSIS-BOTTOM
125 AD92-00005A ASSY-PCB DECK FPC
128 AD97-04462A ASSY-ROTARY FPC ALL
250 AD64-00422A CASE-TOP;W-PJ,ABS94HB
500 AD97-04370A ASSY-DECK;DE-10 NTSC
905 AC60-10054A SCREW-TAPTITE(2X6);BLK ALL
907 AC60-10024A SCREW-MACHINE(2X3);YEL ALL
