Samsung Electronics 2-21
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
122 AD63-00064D COVER-JIG;W-PJ/D/GRAY,ABS94HB
150 AD97-03188A ASSY-CASE REAR;ASS'Y:Hi8 (D.ZOOM)- SCL810
AD97-02604A ASSY-CASE REAR;ASS'Y:Hi8 (S.SHOT) SCL860/SCL870
151 AD64-00418E CASE-REAR;Hi8 (D.ZOOM) SCL810
AD64-00418C CASE-REAR;Hi8 (S.SHOT) SCL860/SCL870
152 AD61-00578A BRACKET-REAR(W2);SUS304 T0.8 1/2H
153 AD64-00423A BUTTON-SNAP SHOT;ABS94HB HF0660I G3532
154 AD61-00573A HOLDER-BATTERY EJECT;ABS94HB HF0660I G3532
155 AD61-00574A HOLDER-SNAP SHOT;POM NTR
156 AD64-00431A KNOB-BATTERY EJECT;ABS94HB HF0660I G3532
157 AD64-00432A KNOB-ZOOM;ABS94HB HF0660I G3532
158 AD61-00602A HOLDER-ZOOM;POM NTR
160 AD64-00176B KNOB-DIDECTOR;ABS94HB HF0660I G3532
161 AD64-00182B LOCKER-BATTERY;POM BLK
162 AD61-00218A SPRING-BATTERY EJECT;SUS 304 WPB
163 AD61-00219A SPRING-BATTERY LOCK;SUS 304 WPB
164 AD61-00220A SPRING-SNAP SHOT;SUS 304 WPB
165 AD97-02894A ASSY-REAR B'D;ASSY(Hi8)
220 AC61-32047A PLATE-NUT;SECC T0.8
906 AC60-10061A SCREW-TAPPING(T2X5);BLK
