Samsung SCL810 - Page 80

Samsung Electronics 3-13
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
J53 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J55 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J56 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J57 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J61 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
L50 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
LF10 AC27-32001F COIL-LINE FILTER;BSF-2123,20MH,2OHM,ST,-
PC10 0604-000119 PHOTO-COUPLER;TR,200-400%,200mW,DIL-4,ST
Q52 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
R00 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R10 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R11 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R13 2003-000771 R-METAL OXIDE(S);68Kohm,5%,2W,AA,TP,4x12
R14 2007-000598 R-CHIP;22OHM,5%,1/8W,DA,TP,3216
R15 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R16 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R17 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R18 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R19 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R20 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R21 2001-000374 R-CARBON;15OHM,5%,1/4W,AA,TP,2.4X6.4MM
R30 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
R30 2201-001005 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,11X
R30A 2201-001005 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,11X
R50 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R51 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R53 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R54 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R55 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216
R57 2007-000938 R-CHIP;47KOHM,1%,1/10W,DA,TP,2012
R58 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R59 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R60 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R61 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
R62 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R63 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R64 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R65 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R66 2007-000406 R-CHIP;15KOHM,1%,1/10W,DA,TP,2012
R68 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R70 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012
R71 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R72 2007-000582 R-CHIP;22KOHM,1%,1/10W,DA,TP,2012
R74 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R76 2005-000102 R-WIRE WOUND;0.1ohm,1%,1W,AA,TP,4.5x11mm
R77 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
R79 2007-001067 R-CHIP;6.8KOHM,1%,1/10W,DA,TP,2012
R80 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
T10 AD26-00026A TRANS POWER;AA-E6,AA-E6,1.4mH,6P,100~260
VR50 2101-001049 VR-ROTARY;500ohm,-,-,-
