NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
HI8 NOR HI8 NOR D7 D6 D5 D4 D3 D2 D1 D0
Samsung Electronics1-8
Alignment and Adjustment
095 B8 - - - ; ZOOM VARIABLE CORVE OPTION
096 31 31 31 31 ; #0D3 LENS CHECK OPTION (‘1’= WIDE END SKIP)
097 66 - - - ;AE WEIGHT (B-2A);(WEIGHT/255)
098 36 - - - ;AGC MAX Y SETUP(#23F)
099 16 - - - ;FOCUS MIDDLE MARGIN LOW BYTE CHANGED BY ( LENS ADJUST (#0DE)
09A 00 00 00 00 ;FOCUS MIDDLE MARGIN HIGH BYTE CHANGED BY ( LENS ADJUST (#0DE)
09B ~ 0A0 AGC ADJUST SHUTTER VALUE
0A1 B4 B4 96 96 ;FADE TIME (#3 SEC*60=180==B4
0A2 90 - A1 A2 ;RGAIN5100_L CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A3 01 - 01 01 ;RGAIN5100_H CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A4 98 - 9C 82 ;BGAIN5100_L CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A5 01 - 01 01 ;BGAIN5100_H CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A6 D2 - B8 CC ;RGAIN3100_L CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A7 00 - 00 00 ;RGAIN3100_H CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A8 F3 - 91 E5 ;BGAIN3100_L CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0A9 01 - 01 01 ;BGAIN_3100H CHANGED BY ( WHITE BALANCE ADJUST(#0CF)
0AA 6C - - - ; FOCUS RESET LOW(16X,22X LENS) CHANGED BY ( LENS ADJUST (#0DE)
0AB 81 - - - ; FOCUS RESET HIGH(16X,22X LENS) CHANGED BY ( LENS ADJUST (#0DE)
0AC 21 - - - ; ZOOM RESET LOW(16X, 22X LENS) CHANGED BY ( LENS ADJUST (#0DE)
0AD 87 - - - ; ZOOM RESET HIGH(16X, 22X LENS) CHANGED BY ( LENS ADJUST (#0DE)
0B3 40 - - - ; HALL CLOSE TARGET
0B4 95 - - - ; IRIS CONTROL AT ADJUSTMENT ;UPPER 8 BIT
0B5 87 - - - ; IRIS CONTROL MIN LOW BYTE CHANGED BY ( IRIS ADJUST (#0CE)
0B6 72 - - - ; IRIS CONTROL MIN HIGH BYTE CHANGED BY ( IRIS ADJUST (#0CE)
0B7 81 - - - ; ZOOM VR CENTER VALUE SAVE ADDR. BY #0D6 CHANGED BY ( ZOOM VR-CENTER ADJUST (#0D6)
0B8 20 - - - ; ZOOM VR CENTER MARGEIN
0BC 34 - - - ; AGC MIN
0BD D0 - E0 C8 ; AGC MAX
0BE 89 - - - ; HALL WIDTH
0BF 60 - - - ; HALL REF. START
0C0 4C - - - ; HALL GAIN. START
0C1 42 - - - ; HALL MIN CHANGED BY ( HALL ADJUST (#0CD)
0C2 DF - - - ; HALL MAX CHANGED BY ( HALL ADJUST (#0CD)
0C7 00 - - - ; IRIS CONTROL MAX LOW BYTE CHANGED BY ( IRIS ADJUST (#0CE)
0C8 C2 - - - ; IRIS CONTROL MAX HIGH BYTE CHANGED BY ( IRIS ADJUST (#0CE)
0C9 02 - - - ; FOCUS TELE MARGIN LOW BYTE CHANGED BY ( LENS ADJUST (#0DE)
0CA 00 - - - ; FOCUS TELE MARGIN HIGH BYTE CHANGED BY ( LENS ADJUST (#0DE)
0CB 28 - - - ; FOCUS WIDE MARGIN LOW BYTE CHANGED BY ( LENS ADJUST (#0DE)
0CC 00 - - - ; FOCUS WIDE MARGIN HIGH BYTE CHANGED BY ( LENS ADJUST (#0DE)
0D7 01 - - - ; ZOOM/FOCUS CHK=ONE AF ENABLE BIT 00~03
0E0 1F - - - ; Y_SOLARI : ART EEPROM #247 AA’=ALL DATA INITIAL)
0E1 00 - - - ; C_SOLARI : ART EEPROM #29F,#2A0”
0E9 2B 32 3C 3C ; CINEMA MODE FLEX ZONE VERTICAL START LIMIT
0EA 00 00 01 01 ; CINEMA MODE FLEX ZONE VERTICAL END LIMIT HIGH
0EB DF DF 0D 0D ; CINEMA MODE FLEX ZONE VERTICAL END LIMIT LOW
0EC DC 00 EC EF ; FLEXZONE AF/AE WINDOW H OFFSET DSP
0ED FA F9 FA FB ; FLEXZONE AF/AE WINDOW V OFFSET DSP
0EE B0 D4 D1 CA ; FLEXZONE AF/AE WINDOW H OFFSET DIS
0EF E8 ED E8 E9 ; FLEXZONE AF/AE WINDOW V OFFSET DIS
0F0 01 01 01 01 ; V_YUKO(HIGH) VERTICAL EFFECTIVE H LINE NUMBER HIGH
0F1 03 02 2F 2B ; V_YUKO(HIGH) VERTICAL EFFECTIVE H LINE NUMBER LOW
0F2 01 01 01 01 ; H_YUKO(HIGH) HORIZENTALL EFFECTIVE PIXEL NUMBER HIGH
0F3 80 80 78 78 ; H_YUKO(HIGH) HORIZENTALL EFFECTIVE PIXEL NUMBER LOW
0F4 81 81 00 7E ; H_HOSEI HORIZENTAL START/STOP OFFSET
