Samsung SCX-4521F User Manual

Using Your Printer in Linux
32
Scanning a Document
You can scan a document using the MFP Configurator window.
1 Double-click the MFP Configurator on your desktop.
2 Click the button to switch to Scanners Configuration.
3 Select the scanner on the list.
When you have only one MFP device and it is connected
to the computer and turned on, your scanner appears on
the list and is automatically selected.
If you have two or more scanners attached to your
computer, you can select any scanner to work at any
time. For example, while acquisition is in progress on the
first scanner, you may select the second scanner, set the
device options and start the image acquisition
simultaneously.
N OTE : The scanner name shown in Scanners configuration
can be different from the device name.
4 Click Properties .
5 Load the document to be scanned face up into the ADF
(Automatic Document Feeder) or face down on the
document glass.
6 Click Preview in the Scanner Properties window.
Click your
scanner.
The document is scanned and the image preview appears
in the Preview Pane.
7 Change the scan options in the Image Quality and Scan
Area sections.
•
Image Quality : allows you to select the color
composition and the scan resolution for the image.
•
Scan Area : allows you to select the page size. The
Advanced button enables you to set the page size
manually.
If you want to use one of the preset scan option settings,
select from the Job Type drop-down list. For details about
the preset Job Type settings, see page 33.
You can restore the default setting for the scan options
by clicking
Default .
8 When you have finished, click Scan to start scanning.
The status bar appears on the bottom left of the window
to show you the progress of the scan. To cancel scanning,
click
Cancel .
9 The scanned image appears in the new Image Editor
window.
If you want to edit the scanned image, use the toolbar.
For further details about editing an image, see page 33.
Drag the pointer to
set the image area
to be scanned.

Samsung SCX-4521F Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
I/O ports	USB
Dimensions (WxDxH)	438 x 374 x 368 mm
All-in-one functions	Fax, Scan
Standard media sizes	Legal, A4, Letter, Folio, Executive, JIS B5, A5, A6, Envelope 6 3/4, 7 3/4, #9, #10, DL, C5, C6, ISO B5, Monarch Envelopes 76 x 127 mm ~ 216 x 356 mm
Media types supported	Plain Paper, Transparency, Labels, Card Stock, Envelope, Bond, Thick, Thin, Color Paper, Preprinted
Compatible operating systems	Windows 98/Me/NT4.0/2000/XP, \\r Linux OS (Red Hat 8.0-9.0, Fedora Core 1-3, Mandrake 9.0-10.2, SuSE 8.2-9.2)\\r Mac 10.3
Maximum print size	210 x 297 mm
Paper tray media types	Envelopes, Plain paper
Recommended media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A4
Grayscale levels	256
Scanner features	Twain, WIA
Input color depth	24 bit
Maximum scan resolution	4800 x 4800 DPI
Maximum number of copies	99 copies
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Auto-redialing	Yes
Fax speed dialing (max numbers)	100
Total input capacity	150 sheets
Auto document feeder (ADF) input capacity	30 sheets
Display	LCD
Product color	White
Market positioning	Home & office
Internal memory	8 MB
Card reader integrated	-
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Maximum duty cycle	10000 pages per month
Page description languages	SPL
Package weight	12300 g
Power consumption (average operating)	- W

Weight and Dimensions

Depth	374 mm
Width	438 mm
Height	368 mm
Weight	10400 g
