Alignment and Adjustments
Samsung Electronics
Service Manual
4-18
STATUS LCD Display Descriptions
BY PASS JAM [Bypass Jam] When the machine detected the non feeding from BYPASS Tray.
GROUP is not available Group Not Available You have tried to select a group location where only a single
Location number can be used.
RETRY REDIAL? Retry Redial ? the machine is waiting for the programmed interval to automatically
redial a previously busy station.
NO. NOT ASSIGNED NO. Not Assigned The speed dial location you tried to use has no number assigned to it.
Load document Load Document You have attempted to set up a sending operation with no
Document loaded.
Memory full and canel the job Cancel ? When the machine has encountered the memory full during storing
1:Yes 2:No the document into memory, the machine display the "CANCEL ?" to
operator whether he/she make a decision the canceling the job or
accept the scanned page so far to transmit the remained
documents.
Job has not been created Operation Not When operator is doing in ADD/CANCEL operation and
Assigned There is no job to handle if operator entered the job no.
Low Heat Error [Low Heat Error] Temperature could not reach certain level.
Open Fuser Error Open Fuser Error The thermister has been disconnected.
Over Heat Error [Over Heat] Temperature has gone up very high degree.
[Jam 1] When the machine detected the toner cartridge has not
[No Catridge] been installed, or detected jam1 in warmup state.
Memory Dial Full Memory Dial Full During Auto dial transmission when all 15 jobs are configured and
try to add 16th job
