Exploded view and Part List
3-2
This Document can not be used without Samsung's authorization
3-2. Parts List
Location NO. Description SEC CODE
QAN02
INTENNA-SGHE360 GH42-00717A
QAN05
MEC-INTENNA CONN RUBBER GH75-08200A
QBA01
BATTERY-800MAH,SIL,ENG,M GH43-02067A
QCA01
UNIT-CAMERA GH59-02420A
QCK01
MEC-CAMERA KEY GH75-07171A
QCR11
SCREW-MACHINE 6001-001654
QCR12
SCREW-MACHINE 6001-001530
QCR21
SCREW-MACHINE 6001-001507
QCW02
PCT-WINDOW CAMERA GH72-24951A
QFL01
MEC-FOLDER LOWER GH75-08048A
QFR01
MEC-FRONT COVER GH75-08049A
QFU01
MEC-FOLDER UPPER GH75-08047A
QFU03
NDC-FOLDER DECO DUMMY GH71-05554A
QIF01
PMO-IF COVER GH72-20212A
QKP01
MEC-KEYPAD GH75-08052A
QKP02
MEC-KEY FOLD GH75-08051A
QLC01
MEA-LCD MODULE KIT(E360) GH97-05188A
QME01
UNIT-METAL DOME F/K GH59-02396A
QME03
UNIT-MP3 KEY GH59-02398A
QMI01
MICROPHONE-ASSY-SGHE360 GH30-00224A
QMO01
MOTOR DC-SGHE360 GH31-00198A
QMP01
PBA MAIN-SGHE360S MAIN GH92-02402A
QMW02
PCT-WINDOW MAIN GH72-24952A
QMW03
PCT-WINDOW SUB GH72-24950A
QRF01
MPR-RF SHEET GH74-17797A
QSC01
MPR-SHEET SCREW GH74-17787A
QSC14
MPR-TAPE FRONT FPC GH74-08876A
QSP01
SPEAKER 3001-001844
QVK01
UNIT-VOLUME KEY GH59-02397A
QVO01
MEC-VOLUME KEY GH75-07170A
QRE01
MEC-REAR COVER GH75-08050A
QRF03 PMO-EAR COVER V2 GH72-23676A
QMI03 MEC-RUBBER MIC GH75-08856A
