Flow Chart of Troubleshooting
This Document can not be used without Samsung's authorization
7-3
7-2. Initial
U305 pin 4 (RSTON) ="H"
Initial Failure
Check the circuit related to reset
END
No
Yes
Is UCP200 R206, R207
OK?
Yes
Yes
No
Check the UCP200
Check the 16bit data signal
&memoryCE
Yes
