SGH-E770 Flow Chart of Troubleshooting
This Document can not be used without Samsung's authorization
2-7
2-1-3. Sim Part
The voltage is 2.8V
at the pin #1 of ZD307?
Check the UCP301
"Insert SIM" is displayed on the LCD
END
Check the SIM Card
YES
NO
NO
YES
Is there any signal
pin #2,3,4 of ZD307 ?
Check the UCP301 & UCP201
