Samsung Electronics38
PCB Diagram
■
Parts List
D101 DIODE-RECTIFIER UG2D,200V,2A,DO-204AC,TP 1
D701,D702,D703 DIODE-RECTIFIER MRA4005,600V,1A,SMA,TP 3
BD71 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1
ZD11 DIODE-ZENER BZX84C3V6,3.6,350mW,SOT-23,TP 1
ZD71 DIODE-ZENER 1N4749A,24V,5%,1W,DO-41,TP 1
ZD12 DIODE-ZENER BZX84-C11,10.4-11.6V,350MW,SOT-23,TP 1
CD11 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1
Q201,Q401,Q602 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,1 3
Q603 TR-SMALL SIGNAL MMST2907A,PNP,200mW,SOT-23,TP,100- 1
Q301,Q302,Q601 TR-DIGTAL DTC114EKA,NPN,200mW,10K/A0K,SOT-23,TP 3
IC05,IC06,IC07 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 3
PC02 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST 1
PC01,PC31,PC32 PHOTO-COUPLER TR-100-300,200mW,SOP,TP 3
IC08 IC-SOURCE DRIVER TD62783AFW,SOL,18P,-,8,-500MA,TP 1
IC51 IC-EEPROM 93LC56,128x16Bit,SOP,8P,150MIL,-,2.5V,- 1
IC03 IC-VOLTAGE COMP. 7533,TO-92,3P,-,SINGLE,-,-,PLASTIC 1
IC01 IC-PWM CONTROLLER 255,DIP,8P,300MIL,PLASTIC,-0.3/7 1
VA71,VA72,VA73 VARISTOR INP14D561K 3
R703,R704 R-METAL OXIDE(S) 4.7Kohm,5%,2W,AA,TP,4x12mm 2
R701,R702 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm 2
R601,R602 R-CHIP 10Kohm,1%,1/10W,TP,1068 2
R504,R505,R506 R-CHIP 330ohm,5%,1/10W,TP,1068 3
R302,R604,R605 R-CHIP 470ohm,5%,1/10W,TP,1068 1
R201,R207,R208,R301 R-CHIP 1Kohm,5%,1/10W,TP,1068 8
R401,R403,R607,R903
R603,R901 R-CHIP 4.7Kohm,5%,1/10W,TP,1068 2
R206,R902 R-CHIP 10Kohm,5%,1/10W,TP,1068 2
R510,R511 R-CHIP 47Kohm,5%,1/10W,TP,1068 2
R606 R-CHIP 560ohm,5%,1/10W,TP,1068 1
R706 R-CHIP 100Kohm,5%,1/8W,TP,2012 1
R202,R203,R304,R205 R-CHIP 100Kohm,5%,1/4W,TP,3216 4
R707 R-CHIP 1Kohm,5%,1/8W,TP,2012 1
R102,R103,R104 R-CHIP 220Kohm,5%,1/4W,TP,3216 3
R106,R407 R-CHIP 220ohm,5%,1/8W,TP,2012 2
R101 R-CHIP 4.7Kohm,5%,1/8W,TP,2012 1
R105 R-CHIP 470ohm,5%,1/8W,TP,2012 1
R402,R501,R502,R503 R-CHIP 6.8Kohm,1%,1/10W,TP,1068 4
R303 R-CHIP 8.2Kohm,1%,1/10W,TP,1068 1
C104 C-CERAMIC,DISC 2.2NF,20%,400V,Y5U,BK,12.5x6mm,10 1
C103,C107,C110,C112,C201 C-CER,CHIP 100nF,+80-20%,50V,Y5V,TP,2012 11
C202,C500,C501,C502,C503
C901
Specification RemarkQ'TYDescriptionLocation No.
DB98_00000A(1)_1 1/29/04 4:23 PM Page 38
